Magnabend kantvik

Med Magnabend kan du bocka alla de former som konventionella maskiner inte klarar av. Du kan bl.a. forma lådor, tråg, runda former, stängda och djupa kanaler. Tack vare de patenterade gångjärnen och det tunna överprismat får du fritt svängrum i höjd, djup och sidled. Du kan låta plåten sticka ut i sidled utan att gaveln tar emot. När plåten placerats i önskat läge låser du prismat med elektromagneten och kan sedan bocka till önskad vinkel. Med Magnabend kan du bocka plåt oavsett material och storlek, perfekt vid tillverkning av specialdetaljer eller som komplement i plåtverkstaden. Med de större modellerna av Magnabend kan du även bocka fasadplåt upp till 3,2 meter.  Licato är generalagent för Magnabend i Sverige, Norge, Finland, Danmark och Island.

The fundamental principle of the MAGNABEND™ machine is that it uses electromagnetic, rather than mechanical, clamping. The machine is basically a long electromagnet with a steel clampbar located above it. In operation, a sheetmetal workpiece is clamped between the two by a force of many tonnes. A bend is formed by rotating the bending beam which is mounted on special hinges at the front of the machine. This bends the workpiece around the front edge of the clamp-bar. Using the machine is simplicity itself... slip the sheetmetal workpiece in under the clamp-bar; press the start-button to initiate clamping; pull the handle to form the bend to the desired angle; and then return the handle to automatically release the clamping force. The folded workpiece may now be removed or repositioned ready for another bend. If a large lift is required, eg. to allow the insertion of a previously bent workpiece, the clamp-bar may be manually lifted to any required height. Conveniently located adjusters at each end of the clamp-bar allow easy adjustment of the bend radius produced in workpieces of various thicknesses. If the rated capacity of the MAGNABEND™ is exceeded then the clamp-bar simply releases, thus minimising the possibility of damage to the machine. A graduated scale continuously indicates the bend angle.
